A protection system is made up of three triple modular redundant (TMR) PPRA I/O packs that are mounted to a TREA terminal board and have a WREA option board attached.
Three triple modular redundant (TMR) PPRA I/O packs installed to a TREA terminal board with the WREA option board included make up a protective system.
Ambient Temperature Range: -30 to 65 degrees Celsius
Probe Power: -24 Volt DC, with a load of 12 milliamps per sensor
Software Version Number Data Length: 7 bytes (up to 6 bytes of data plus "*")
Frame Rate: May support multiple frame rates such as 3.125, 6.25, 12.5, 25, 50, and 100 Hertz
IS220PDOAH1A is compatible with six discrete output terminal boards, including both SRLY and TRLY types. It features three connectors: one DC connector and two RJ45 Ethernet connectors.The memory types supported are flash and RAM. There are two Ethernet ports available. The device also has four LED indicators: Power, Attention, TxRx (transmit/receive), and Link. For power management, it accepts a 28-volt input. The quantity of relay channels it can handle is twelve.
