IS200DSPXH1CAA GE EX2100, Digital Signal Processor Control Board

Description:

The IS200DSPXH1CAA is a printed circuit board (PCB) produced by GE as a replacement component for their Speedtronic Mark VI system. The Mark VI is one of GE’s control systems for gas and steam turbines, featuring triple modular redundancy with Ethernet capabilities, proprietary software such as CIMPLICITY, and a Windows-based operating system.

Within the Mark VI, the IS200DSPXH1CAA serves as a Digital Signal Processor Control Board. It is important to ensure that you order the correct version of this board for your specific system, as multiple versions are available.

This PCB is designed for use in Innovation series drives and EX2100 exciters. The digital signal processor on the board operates at a frequency of 60 MHz. An ASIC revision ID register, readable by the DSP, is typically included with the board and encompasses most of its specialized and support functions. Onboard firmware is stored in flash memory.

The IS200DSPXH1CAA features a right-angled backplane connector (P1). Additionally, it has two connectors mounted on its front faceplate and another vertical pin connector located just behind these connectors. There are two LED indicators on the faceplate. The board includes sixteen integrated circuits, resistors, resistor network arrays, transistors, diodes, and capacitors. It comes factory-drilled for ease of installation.
