Vibration

CMC16 Vibration 200-530-SSS-HHh Condition Monitoring Card

• 16 individually configurable dynamic channels
• 16 parallel programmable anti-aliasing filters and ADCs
• First 4 channels also configurable as tacho inputs
• Last 12 channels also configurable as process values
• VME architecture
• Configurable Synchronous and Asynchronous sampling
• High resolution 3200- line FFT
• 10 fully configurable frequency bands per channel
• 6 configurable alarms per band with hysteresis deadbands
• Schedule, ‘on-alarm’ and ‘on exception’ based logging
• Ethernet and Serial RS-485 communication options
• On-board buffer storage
• Status indication by 3-colour LED on front panel
• Live insertion / removal of cards with automatic configuration

Tags :

view detail

EA902 Vibration 913-902-000-011 A1-E4000-F0-G0 Extension Cable

EA402 extension cable

:FEP covered 70 Ω coaxial cable, Ø 3.6 mm

: Self-locking miniature coaxial connectors.
Note: When connecting, these should be hand-tightened until locked.

Tags :

view detail

EA402 Vibration 913-402-000-012 A1-E040-F0-G000 Extension Cable

EA402 extension cable

:FEP covered 70 Ω coaxial cable, Ø 3.6 mm

: Self-locking miniature coaxial connectors.
Note: When connecting, these should be hand-tightened until locked.

Tags :

view detail

CE620 Vibration 444-620-000-111 -A1-B100-C01 Piezoelectric Accelerometer

• Voltage output signal: 100 or 500 mV/ g
• Frequency response:
0.5 to 14 000 Hz (100 mV/ g versions)
0.2 to 3 700 Hz (500 mV/ g versions)
• Temperature range:
−55 to 120 °C (100 mV/ g versions)
−55 to 90 °C (500 mV/ g versions)
• Isolated electronics with internal shield for reduced noise and improved bias-voltage stability
• Ground isolated from case
• Available as a sensor only or with an integral cable
• Available in standard versions and Ex versions certified for use in hazardous areas

Tags :

view detail

TQ402 Vibration 111-402-000-013 Proximity Transducer

• Non-contact measurement system based on eddy-current principle
• Ex certified versions for use in hazardous areas (potentially explosive atmospheres)
• Conforms to API 670 recommendations
• 1, 5 and 10 m systems
• Temperature-compensated design
• Voltage or current output with protection against short circuits
• Frequency response: DC to 20 kHz (−3 dB)
• Measurement range: 2 or 4 mm
• Temperature range: −40 to +180 °C

Tags :

view detail

CA202 Vibration 144-202-000-205 Piezoelectric Accelerometer

CA202 Vibration 144-202-000-205
• High sensitivity: 100 pC/g
• Frequency response: 0.5 to 6 000 Hz
• Temperature range: −55 to 260 °C
• Available in standard versions and Ex versions certified for use in potentially explosive atmospheres
• Symmetrical sensor with internal case insulation and differential output
• Hermetically welded austenitic stainless-steel case and heat-resistant stainless-steel protection hose
• Integral cable

Tags :
