IQS452 Vibration 204-452-000-011 Signal Conditioner

• For use with the TQ 400 series transducers

• Temperature compensated • Conforms to API 670 recommendations

• Certified to CENELEC standards • Output protected against short circuits
• Voltage or current output

Item NO.:
IQS452
Payment:
T/T
Market Price:
$3000
Product Origin:
Switzerland
Color:
Depends on material
Shipping Port:
Xiamen
Lead Time:
5-7 days
Goods Stock:
8
Product weight:
0.25 kg

Inquiry now

product introduction

Manufacture	Vibration
Model	IQS452
PN No.	204-452-000-011
Catalog	NIL
Description	Signal Conditioner
Origin	Switzerland
HS CODE	85389091
Dimension	854 (CM)
Weight	0.25 kg

Description:

The HF modulator/demodulator in the IQS 451, 452, 453 signal conditioner supplies a driving signal to the matching proximity transducer. This generates the necessary electromagnetic field used to measure the gap between the transducer tip and the target, using the eddy current principle. As this gap distance var ies, the output of the conditioner provides a dynamic signal proportional to the movement of the target.

The power for the transducer-conditioner system is obtained from the associated processor modules or rack power supply. The conditioner circuitry is made of high-quality components and is mounted and pot ted in an aluminium extrusion to seal out moisture and dust. Please refer to the accessory list for the range of available enclosures for additional protection and for multi-channel installations.

Order Number:

IQS452 204-452-000-011

IQS452 204-452-000-021
IQS452 204-452-000-221

Datasheet Link:

IQS452 Vibration 204-452-000-011 Signal Conditioner PDF Datasheet
