• Optional diagnostic circuitry detects sensor, cabling and/or signal conditioner problems

• Suitable for use in functional safety contexts: SIL 2 in accordance with IEC 61508 and Cat 1 PL c in accordance with ISO 13849

• IQS900: Removable screw-terminal connectors and DIN-rail mounting

• Temperature compensated • Conforms to API 670 recommendations

• Certified to CENELEC standards • Output protected against short circuits
• Voltage or current output

 • Temperature compensated • Conforms to API 670 recommendations

 • Certified to CENELEC standards • Output protected against short circuits
 • Voltage or current output

• Signal interface card with 4 dynamic signal inputs and 2 tachometer (speed) inputs, for the MPC4 machinery protection card

• Screw-terminal connectors (48 terminals) for all input/output connection

• Contains 4 relays which can be attributed to alarm signals, under software control

• 32 fully-programmable open-collector outputs (jumper selectable) to IRC4 and RLC16 relay cards

Removable screw-terminal connectors

:FEP covered 70 Ω coaxial cable, Ø 3.6 mm

 :FEP covered 70 Ω coaxial cable, Ø 3.6 mm
