Part Number: IS200ERGTH1A
Analog output current: 0-20 mA
Excitation voltage: 24 V dc
Maximum Lead Resistance: 15Ω
Processor: 32-bit digital signal processor
Analog output current: 0-20 mA
Operating temperature: 30 to 50 °C
Frequency: 50 or 60 Hz
Availability: In Stock
Part Number:IS200EXMDG1B
Functional Acronym/Abbreviation: EXMD
Hardware Form: G1B
Number of Female Connection Points: Two
Number of Vertical Pin Connectors: 2, Varying Sizes
Maximum Output Current (Single DACA Module): 9.5 ADC
Output Power Rating: 1000 W
Power Conversion: 115/230 VAC input to 126 VDC output
Power Distribution: 125 VDC
Temperature : -22 to +140 °F (free convection)
IS200DSPXH1DBD Digital Signal Processor Control Board is mounted in the board rack and connects to the backplane through a 4-row, 128-pin DIN connector (P1).
IS200DSPXH1CAA Digital Signal Processor Control Board is mounted in the board rack and connects to the backplane through a 4-row, 128-pin DIN connector (P1).
IS200DSPXH1BBD Digital Signal Processor Control Board is mounted in the board rack and connects to the backplane through a 4-row, 128-pin DIN connector (P1).
Part Number: IS200EXHSG3AEC
Functional Acronym: EXHS
PCB Coating: Normal Coating
Functional Revision 1: A
Functional Revision 2: E
Artwork Revision:C
Availability: in stock
IS200EGDMH1A is an Exciter Ground Detector Module manufactured and designed by General Electric as part of the EX2100 Series used in Excitation Control Systems.
