KJ1501X1-BC3 Emerson, System Dual DC Power Supply

Description:

The Emerson KJ1501X1-BC3 is a System Dual DC Power Supply designed for use in hazardous atmospheres and is ATEX certified. This power supply unit is engineered to provide reliable and efficient power to Emerson's process control systems. Key features include:
-Dual DC Output Voltage: The KJ1501X1-BC3 offers dual DC output voltage capabilities, supporting both 12 VDC and 24 VDC input ratings.
-Power Ratings: It provides 12 VDC at 13 A (when using 12 VDC input) and 12 VDC at 8 A (when using 24 VDC input), along with 5.1 VDC at 2.0 A and 3.4 VDC at 2.0 A, totaling 10.2 W from the combined outputs of +5.1 VDC and +3.4 VDC.
-Environmental Durability: With an ambient temperature range of -40°C to +70°C, the unit is designed to withstand harsh environmental conditions, including shock and vibration.
-Safety and Compliance: The KJ1501X1-BC3 adheres to safety standards, including ISA-S71.04 – 1985 Airborne Contaminants Class G3 and Relative Humidity of 5% to 95% Non-Condensing.
-ATEX Certification: The product is certified for use in hazardous atmospheres, ensuring safety in potentially explosive environments.
-Compact Design: Measuring approximately 30mm x 20mm x 20mm and weighing 2kg, the KJ1501X1-BC3 is compact and easy to install.

Frequently Asked Questions:
1.What is the total output power of the KJ1501X1-BC3 when operating at 70°C?
The total output power is 10.2 W at 70°C (combined outputs of 5 VDC and 3.3 VDC) .

2.What is the ambient temperature range for the KJ1501X1-BC3?
The ambient temperature range is from -40°C to +70°C .

Datasheet Link:

KJ1501X1-BC3 Emerson, System Dual DC Power Supply PDF datasheet
