IS210BAPAH1A GE MKVI, ANALOG PROCESSOR MODULE

Description:

The IS210BAPAH1A serves as an Analog Processor module and is a key component of the Mark VI or Mark VIe systems, both of which are GE products designed to manage steam or gas turbines. The Mark VI features centralized control, with a Central Control Module at its core that houses 13- or 21-slot VME card racks. This platform is ideal for integrating power island and balance of plant controls. In contrast, the Mark VIe is a distributed control system, with control processing dispersed across various nodes that are coordinated by a central scheduler.
When paired with a SAMB terminal board, the IS210BAPAH1A forms an Acoustic Monitoring Input pack, which is compatible with frame 6/7/9 gas turbines. The module itself is housed in a slim black casing with ventilation openings at the top and bottom. The rear side has top and bottom flanges with mounting holes, while the front faceplate features a single jack connector and two sets of LED indicators.
Configuration and diagnostics of the IS210BAPAH1A can be performed using the ToolboxST application. The acoustic monitoring pack is capable of calculating the broadband root-mean-square (RMS) energy of time-domain sampled data within a frequency range of 0 to 5000 Hz. It can also conduct RMS scan averages and peak-to-peak scan averages. For more detailed information on the pack, including installation procedures, functions, and handling guidelines, one can refer to the manufacturer's publications such as user guides, manuals, and datasheets.

Frequently Asked Questions:

1.What systems is the IS210BAPAH1A used in?
The IS210BAPAH1A is used in the Mark VI and Mark VIe systems, which are designed to manage steam or gas turbines.

2.How can the configuration and diagnostics of the IS210BAPAH1A be carried out?
The configuration and diagnostics of the IS210BAPAH1A can be carried out through the ToolboxST application.

Datasheet Link:

IS210BAPAH1A GE MKVI, ANALOG PROCESSOR MODULE PDF Datasheet
