IS200EMCSG1A GE EX2100, EXCITER MULTIBRIDGE CONDUCTION SENSOR

Description:

Functional Description
The IS200EMCSG1A, a Multibridge Connector Sensor Card developed by General Electric, is an integral part of the Mark VI Control system. Although no longer in production, it continues to play a critical role in monitoring and controlling power generation processes through its four conduction sensors. These sensors, labeled E1, E2, E3, and E4, are meticulously integrated into the board and are essential for ensuring precision and reliability in power generation.

Features
One standout feature of the IS200EMCSG1A is its compact size, measuring approximately 4.35 inches in length and 2 inches in width. Despite its small dimensions, the board packs a significant punch in terms of functionality within power generation systems.

Another notable feature is the inclusion of two independent sensor circuits, U1 and U2, strategically positioned between sensors E2 and E3. These additional circuits enhance the board's monitoring and control capabilities, allowing for more precise regulation of power generation processes.

Connectors and Sensors
Powering the IS200EMCSG1A are two six-position plugs located on the edge of the board. This design not only ensures a secure and efficient power supply connection but also simplifies maintenance and replacement when necessary. The four conduction sensors work together to measure and control key parameters within the power generation system, ensuring optimal performance and safeguarding against potential issues.

Availability
While the IS200EMCSG1A may no longer be in production, our commitment to maintaining its availability remains strong. Our dedicated team can efficiently replace the sensor circuits as needed, extending the life of this critical component. This ongoing support underscores our dedication to ensuring the seamless operation of power generation systems.

Datasheet Link:

IS200EMCSG1A GE EX2100, EXCITER MULTIBRIDGE CONDUCTION SENSOR PDF Datasheet
