IS200EHPAG2D GE EX2100, EXCITER HV PULSE AMPLIFIER

Description:

The IS200EHPAG2D module represents the final iteration in the IS200EHPAG series, integral components of the EX2100 series manufactured by General Electric Industrial Systems. This particular module has largely fallen out of use and is scarce in today's marketplace. A distinctive feature of this board includes a comprehensive array of fourteen plug connectors comprising six-position, four-position, and two-position variants – specifically, there are two of each for the six-position, four for the four-position, and eight for the two-position connectors.

On the leading edge of the IS200EHPAG2D board, attention is drawn to an assortment of LED warning lights: five radiate in red, one glows green, while sixteen emit an amber hue. Complementing these plug connectors are three female board connectors strategically positioned on the board itself.

Prior to utilizing or installing the IS200EHPAG2D board, it is imperative to meticulously review the manufacturer's manuals and adhere to the prescribed safety protocols and recommended installation methodologies. For comprehensive guidance applicable not only to this module but across the entire spectrum of EX2100 components, the GEH-6632 EX2100 Excitation Control manual stands as an authoritative reference.
