IS200EPBPG1A GE EX2100, EXCITER POWER BACKPLANE

Description:

The IS200EPBPG1A is an Exciter Power Backplane component meticulously crafted by General Electric, specifically designed for the GE EX2100 Excitation Control System. In GE documentation and manuals, EPBP stands for Exciter Power Backplane, a functional acronym that succinctly captures its essence. This backplane ingeniously integrates M1 Control, M2 Control, and C Control, facilitating seamless communication among various attached modules through an array of DIN connectors.

These modules, which include the EPSM Power Supply, Exciter Ground Detector Modules (EGDM), EDEX, and EDCF, rely on the backplane for efficient data exchange and coordination within the system. The IS200EPBPG1A backplane board is thoughtfully segmented into four distinct areas: M1 Control, M2 Control, C Control, and the Main Connection Area, all harmoniously contributing to the overarching functionality of the M1 Control.

For those seeking a deeper understanding of this intricate backplane configuration, Figure 3-2 in the GEH-6632 GE Publication offers a comprehensive visual representation. Additionally, the product handbook for the IS200EPBPG1A, catalogued under GEI-100463, delves into further detail, providing an exhaustive exploration of its features and functionalities.
