5441-693 Woodward Discrete I/O Module

Description:

 Functional Description

The 5441-693 is a Discrete I/O Module engineered by Woodward, tailored for integration with programmable logic controller (PLC) systems. As a relay module, it leverages relays to adeptly control and switch electrical circuits, thereby enhancing the functionality of PLC systems. The module boasts 13 relay circuits, facilitating extensive control and switching capabilities within a single unit. Its role as a Discrete I/O Module is crucial in amplifying the performance of PLC systems, offering precise and versatile industrial process control.

 Product Attributes

13 Relay Circuits: A key highlight of the module is its comprehensive set of 13 relay circuits. These circuits are central to the module’s ability to manage intricate control and switching operations seamlessly. The abundance of relay circuits supports multifaceted control functions, making it an essential tool for optimizing automation processes.

Seamless PLC Integration: Engineered for compatibility, this module integrates effortlessly with PLC systems. As fundamental components of industrial automation, PLCs benefit from this module's synergistic partnership, expanding their control capabilities and operational scope.

Reliable and Precise Control: Employing relays, the module guarantees dependable and accurate control over electrical circuits. Relays are celebrated for managing high-power equipment efficiently and safely, a critical aspect in industries where precision and safety are vital.

Single Interface Port Convenience: Featuring a singular interface port, the module simplifies connectivity. This user-friendly design promotes easy integration into existing PLC systems, enhancing usability and efficiency.

 Features

Module Installation: Modules are installed into card guides within the control chassis and connected to the motherboard via two screws—one at the top and one at the bottom of the front panel. Additionally, two handles at the top and bottom of the module can be toggled to slightly disengage the board from the motherboard connectors for maintenance or removal.

Interface Port: The module includes a single interface port, which acts as the link between the module and the PLC system. Through this port, the module communicates with the PLC, receiving control signals and transmitting status updates.

Control and Monitoring: With its 13 relay circuits, the module can oversee and regulate various electrical loads or devices. The relays function as switches, allowing the PLC system to activate or deactivate circuits based on received control signals.

 Characteristics

Space-Efficient Design: The module is designed to provide numerous digital input and output channels within a compact footprint, optimizing space utilization.

Digital Output Channels: The module also features several digital output channels to control external devices or actuators. These outputs can toggle between on/off states to activate or deactivate connected equipment or processes.

Communication Protocols: HD Discrete I/O Modules typically support prevalent communication protocols like Modbus, Profibus, Ethernet/IP, among others. This ensures smooth integration with central control systems such as PLCs or DCSs.

Redundancy Features: Advanced HD Discrete I/O Modules may offer redundancy options, including backup channels or module-level redundancy to maintain uninterrupted operation in the event of failures.

Datasheet Link:

5441-693 Woodward Discrete I/O Module PDF Datasheet
