VE4003S2B1 KJ3222X1-BA1+KJ4001X1-CA1 EMERSON Input Module 8 CH 4-20mA Hart

Description:

Ordering Information
Analog Input Cards and Termination Blocks
Description
Model Number
8 Channels 4-20 mA, HART
Standard I/O Termination Block VE4003S2B1**
Redundant Standard I/O Termination Block VE4033S2B1**
Fused I/O Termination Block VE4003S2B2**
4-wire I/O Termination Block VE4003S2B3**
16-Pin Mass Termination Block VE4003S2B4**
24-Pin Mass Termination Block VE4003S2B5**

16 Channels 4-20 ma, HART, Plus Card
16-Channel 2-Wire AI Terminal Block for Series 2 Plus VE4003S2B9
16-Channel 4-Wire AI Terminal Block for Series 2 Plus VE4003S2B10
Redundant 16-Channel 2- & 4-Wire AI Terminal Block for Series 2 Plus VE4033S2B10
48-pin AI Mass Termination Block for Series 2 Plus (to be used with DeltaV Signal Conditioning Cards for
PLC-5 AI, or P+F HiC IS barriers and terminal boards for DeltaV DCS) VE4003S2B11
48-pin AI Mass Termination Block for Series 2 Plus including 16-channel Analog Mass Connection Boards* VE4053S2B11
Redundant 48-pin AI Mass Termination Block for Series 2 Plus (to be used with DeltaV Signal Conditioning
Cards for PLC-5 AI, or P+F HiC IS barriers and terminal boards for DeltaV DCS) VE4033S2B11
Redundant 48-pin AI Mass Termination Block for Series 2 Plus including 16-channel Analog Mass Connection Boards* VE4083S2B11

8 Channels Thermocouple, mV
Standard I/O Termination Block VE4003S4B1
Cold Junction Compensated (CJC) Termination Block VE4003S5B1

Analog Input Card: 8 Channels RTD
Resistant Temperature Device (RTD) Termination Block VE4003S6B1

Isolated Input Card
Isolated Input Terminal Block VE4003S7B1

For more details on the Mass Connection Boards and connection cables, please refer to the M-series Mass Connection Solutions PDS.
Supported on DeltaV v10.3.1 and later. DNV Marine Certification pending. If DNV certification is required or card will be used on earlier DeltaV versions, please request KJ3222X1-BA2.

Frequently Asked Questions:
1.How does VE4003S2B1 isolate?

Each channel is optically isolated from the system and factory tested to 1500V DC. Channels 1, 2, 3, and 4 are isolated from channels 5, 6, 7, and 8 (verified by 1500V DC factory test). Thermocouples attached to channels 1, 2, 3, and 4 are not electrically isolated and should be within + 0.7V DC of each other. Thermocouples attached to channels 5, 6, 7, and 8 are not electrically isolated and should be within + 0.7V DC of each other.

2.What is the payment term?
Only wire transfer

3.When does the warranty period start?
One year from the time the client receives the goods.
