• Non-contact measurement system based on eddy-current principle
• Ex certified versions for use in hazardous areas (potentially explosive atmospheres)
• Conforms to API 670 recommendations
• 1, 5 and 10 m systems
• Temperature-compensated design
• Voltage or current output with protection against short circuits
• Frequency response: DC to 20 kHz (−3 dB)
• Measurement range: 2 or 4 mm
• Temperature range: −40 to +180 °C
The proximity Transducer WW 009 is used in combination with transmitter
or converter for the contactless measurement of shaft vibration or relative
displacement.
The TQ412 and TQ402 proximity transducers are
essentially the same except that the TQ402 is
intended for standard-mount and the TQ412 is for
reverse-mount applications.
• Non-contact measurement system based on eddy-current principle
• Ex certified versions for use in hazardous areas (potentially explosive atmospheres)
• Conforms to API 670 recommendations
• 1, 5 and 10 m systems
• Temperature-compensated design
• Voltage or current output with protection against short circuits
• Frequency response: DC to 20 kHz (−3 dB)
• Measurement range: 2 or 4 mm
• Temperature range: −40 to +180 °C
