Manufacture |
EPRO |
|
Model |
MMS6351/10 |
| PN No. | MMS6351/10 |
|
Catalog |
DOPS AS |
|
Description |
Backplane for System DOPS AS |
| Origin | Germany |
| HS CODE |
85389099 |
|
Dimension |
18*13*4 (CM) |
| Weight |
0.4 kg |
Description:
MMS6351/10 is Backplane for System DOPS AS, manufactured by EPRO.
System DOPS AS
This system offers a special functionality for Astom applications and is certified according to SIL3 – DIN EN 61508 in combination with epro MMS eddy-current measuring chains. This system line requires the following components:
- 3 x monitor MMS 6350 (/DP) (incl. firmware appl. no. 2) Profibus interface: (optional) alternatively
- 3 x monitor MMS 6350D (/DP) (incl. firmware appl. no. 2) with speed display Profibus interface (optional)
In addition:
- 1 x Backplane MMS 6351/10
- 1 x 19“ frame MMS 6352
- 6 x screw terminal MMS 6361
- 6 x cable 0.5 m MMS 6362 alternatively cable 3 m MMS 6360
- 1 configuration kit MMS 6950 3 x blind plates BLE 008, for the installation of monitors without
display
When using this system line, there are additional combinations available via relay outputs beside the normal outputs of the alarms OUT1....OUT6 and the system supervision Channel Clear:
2 v 3 combination output OUT2
2 v 3 combination output OUT4
OUT5 (= TRIP+CC) channel A
OUT5 (= TRIP+CC) channel B
OUT5 (= TRIP+CC) channel C
Frequently Asked Questions:
1.What are input voltage range and input resistance?
Input voltage range: 0...30 Vdc
Input resistance: >100 kOhm
2.What are data of dynamic outputs?
Front socket pulses
The processed input pulses are output as TTL – pulses.
open circuit and short-circuit proof, non-reactive
Nominal range:
TTL – level, 5 VSS
Frequency range:
0 Hz...20 kHz
Permissible load resistance:
> 1 MΩ
Internal resistance:
5,1 kΩ
Datasheet Link:
MMS6351/10 EPRO Backplane for System DOPS AS PDF Datasheet
