IS220YDIAS1A GE Mark VIeS, Discrete Output Pack

Description:

IS220YDIAS1A is Discrete Output Pack, manufactured by GE.
The Discrete Output (IS420YDOAS1B) I/O pack provides the electrical interface between one or two I/O Ethernet networks and a discrete output terminal board. The pack contains a common processor board and an acquisition board specific to the discrete output function. The YDOA is capable of controlling up to 12 relays and accepts terminal board specific feedback. Electromagnetic relays (with types TRLYS1B, D, and F terminal boards) are available. Input to the pack is through dual RJ-45 Ethernet connectors and a three-pin power input. Output is through a DC-37 pin connector that connects directly with the associated terminal board connector. Visual diagnostics are provided through indicator LEDs.The IS220YDIAS1A is a Discrete Contact Input I/O module from General Electric. This module is designed for use within the Mark VIe Speedtronic control system for gas and steam industrial control. While applicable to both gas and steam settings, the Mark VIe Series that this IS220YDIAS1A device belongs to the Mark VIe is one of the last Speedtronic systems designed by GE in a long line of industrial control systems marketed under the Speedtronic name. This means that this IS220YDIAS1A device's greater Mark VIe Turbine Control System Series is one of the more acclaimed General Electric Mark product series on the greater automated industrial marketplace. This IS220YDIAS1A device's Mark VIe Turbine Control System Series additionally is a noticeable step up from the previous Mark V Series as its potential applications are expanded from solely gas and steam turbine automated drive assemblies to wind turbine automated drive assemblies as well.

Hardware Tips and Specifications

The IS220YDIAS1A is part of the Mark IVe control system or part of the Mark VIeS functional safety system. As an I/O pack, it is designed to plug into and be used with specific terminal boards like the IS200STCIS1A and 2A, IS400STCIS1A or 2A, or the IS400TBCIS2C. The IS220YDIAS1A has an on-board power supply with a nominal voltage of 28.0 VDC. Both contact inputs and contact wetting outputs have a max voltage rating of 32 VDC. The IS220YDIAS1A is both UL listed and CE marked.  It can be used in both hazardous and non-hazardous locations. Ratings for hazardous location use can be found within documents like GE’s GEH-6725. This I/O module is designed for use in ambient conditions between -35 and +65 degrees Celsius. Before making any purchase decision here on this IS220YDIAS1A Mark VIe Turbine Control System Series product offering, it is critical to realize that the IS220YDIAS1A Board here is not the original device of its intended Mark VIe Series functional role, given, as explained by GE, the IS220YDIAS1A PCB is edited from its originally-introduced performance specifications and dimensions through the standard A-rated functional product revision.

For a more detailed look at the IS220YDIAS1A, including specifics regarding handling, use, installation, and maintenance, please refer to documentation from the OEM like GE manuals, GE user guides, and data sheets specific to this I/O module. Our company maintains a full warehouse of industrial automation replacement parts to more quickly provide you with what you need.  Most in-stock products will ship the same day your order is received.  Orders placed after 3 pm will typically ship the next day. Given the fact that this IS220YDIAS1A product is not attributable to any continuously-produced General Electric product series, it originally-printed instructional manual materials are generally largely unavailable online. With this being the case, the IS220YDIAS1A functional product number itself can be considered a primary source of IS220YDIAS1A board hardware component and component specification information; coding for these specific details in a series of functional naming segments. To start off, the IS220YDIAS1A functional product number begins with the dual-functional IS220 series tag responsible for indirectly delegating this IS220YDIAS1A PCB's special Mark VIe Series assembly version as well as its domestic original manufacture location.

Frequently Asked Questions:

1.What is the payment term?
Wire transfer only.

2.When does the warranty period start?
One year from the time the client receives the goods.

Datasheet Link:

IS220YDIAS1A GE Mark VIeS, Discrete Output Pack PDF Datasheet
