Manufacture |
GE |
|
Model |
IS220PDIIH1A |
| PN No. |
IS220PDIIH1A |
|
Catalog |
EX2100E |
|
Description |
AUX FUNCTS, TMR |
| Origin | U.S.A. |
| HS CODE |
85389091 |
| Dimension |
8.26*4.19*12.1 (CM) |
| Weight | 0.5 kg |
Description:
The IS200EAUXH1A model is part of the EX2100e systems, manufactured by General Electric Industrial Systems. This model serves as an Exciter Auxiliary Interface, which is what the acronym EAUX stands for. It is a type of printed wiring board known as an I/O Terminal Board. Within the EX2100e system, this model can operate on advanced platforms for various types of generator excitation systems. The "e" in the EX2100e indicates that any models within this system have enhanced technology, distinguishing them from those in the standard EX2100 system.
The IS200EAUXH1A model functions as a Digital Controller in Thyristor-based systems. Its connection to the main control processor is facilitated through the High-speed Serial Link (HSSL) board. Additionally, it connects to the High-speed Serial Link Interface (HSLA) board for host applications. When these boards are linked, the EAUX board generates an output of 41 VDC.
Although the IS200EAUXH1A model lacks a dedicated manual and has limited information available, relevant details can be found in the GEA-S1302A EX2100e Excitation Control 100, 77, 53, and 42 mm Thyristor Systems Users Guide.
Datasheet Link:
IS200EAUXH1A GE EX2100E, AUX FUNCTS, TMR PDF Datasheet
