CPUM Vibration 209-595-067-121 Modular CPU Card

Description:

CPUM 209-595-067-121Modular CPU Card
- Including carrier card and PC/104 CPU module (with integral Ethernet controller)

The CPU M is a modular Central Processing Unit (CPU) card intended for use in Vibro-Meter's VM600
series of Machinery Protection System (MPS) and Condition Monitoring System (CMS) racks. Depending on the system requirements, the CPUM may be used alone in the rack (installed in the front card cage) or in conjunction with the corresponding IOCN Input / Output Card (installed in slot 0 of the rear card cage, directly behind the CPU M).
The modular, highly versatile design of the CPU M means that all rack configuration, display and communications interfacing can be performed from a single card.
The CPU M consists of a base carrier card having two PC/104 type slots. One of a range of PC/104 modules can be installed in each slot. In the standard configuration, a single PC/104 type CPU module is fitted. This provides an RS-232 connection via a DB9 connector, and an Ethernet network connection via an RJ45 connector on the front panel, or alternatively, via the relevant ports on the IOCN, if installed.

Frequently Asked Questions:

1.What is the CPUM processing speed and how much storage is available?

Processor speed : 133 MHz
Memory : 128MB DRAM

2.What are communication ports of CPUM 209-595-067-121?

• RS232/RS422/RS485 : ≤ 115.2 kBaud
• Ethernet : Network interface: 10 Base-T
Data transfer rate: 10 MBits/s
