A6110 EMERSON AMS 6500, Shaft Relative Vibration Monitor

Description:

A6110 is a Shaft Relative Vibration Monitor for AMS 6500 Machinery Health Monitor

-Two-channel, 3U size, 1-slot plugin module decreases cabinet space requirements in half from traditional four channel 6U size cards
- API 670 compliant, hot-swappable module
- Remote selectable limit multiply and trip bypass
- Front and rear buffered and proportional outputs, 0/4-20 mA output, 0 - 10 V output
- Self-checking facilities include monitoring hardware, power input, hardware temperature, sensor, and cable
- Use with displacement sensors PR6422, PR6423, PR6424, PR6425, and driver CON 011/91, 021/91,041/91

Frequently Asked Questions:
1.What number of inputs of A6110?
Two, independent or combined monitoring modes

2.What is the data of Front Panel Buffered Outputs?
- Two, identical to transducer sensor inputs
- ±10 V, >100 kΩ load, freq. range 0.1 - 5
- kHz (-3 dB) 0 - 16 kHz-3 dB ±20%
