8440-1934 WOODWARD, 5A CT inputs / front panel mounting with display

Description:

The Woodward company manufactures the Controller model 8440-1934, which belongs to the easYgen-3000 series. Specifically, this model is designated as the easYgen-3500-1-P1. The P1 series controllers feature a sheet metal enclosure and lack a front display panel, necessitating remote connection for proper operation. Additionally, the P1 series is equipped with a relay output terminal.
When wiring your controller, it's crucial to understand the designated connections for each wire. For instance, when wiring the generator voltage, the connections should be made to terminals twenty-nine through thirty-six, alternating between 120 Vac and 480 Vac. It's important to note that the P2 models have a greater number of terminals compared to the P1 models, and some wiring specifics vary by model. For example, on a P2 model, relay outputs would be wired through terminals one hundred twenty-one to one hundred forty.
The easYgen-3500 models offer a variety of operational features, including run-up synchronization, AMF operation, and peak shaving operations. The controller also boasts extensive capabilities, such as full connectivity to nearly thirty-two generators and up to sixteen LS-5 circuit breaker controllers, all within a single, user-friendly application.

Frequently Asked Questions:

1.How do I wire the generator voltage for the P1 model?
Connect the wires to terminals twenty-nine through thirty-six, alternating between 120 Vac and 480 Vac.

2.What's a special feature of the easYgen-3500 models?
They can connect to many generators and circuit breaker controllers easily.

Datasheet Link:

8440-1934 WOODWARD, 5A CT inputs / front panel mounting with display PDF Datasheet
