330980-50-05 Bently Nevada 3300 XL NSv Proximitor Sensor General Eletric

Description:

The 3300 XL NSv Proximity Transducer system is intended for
use with centrifugal air compressors, refrigeration
compressors, process gas compressors, and other machines
with tight installation requirements. The 3300 XL NSv Proximity
Transducer System consists of:
l a 3300 NSv probe
l a 3300 NSv extension cable
l a 3300 XL NSv Proximitor Sensor(1)
The primary uses for the 3300 XL NSv Transducer System are
for areas where counter bore, sideview, or rearview
restrictions limit the use of standard Bently Nevada 3300 and
3300 XL 5 and 8 mm Transducer Systems. It is also ideal for
small target applications, such as measuring radial vibration
on shafts smaller than 51 mm (2 in) or axial position on flat
targets smaller than 15 mm (0.6 in). It is primarily used in the
following applications on fluid-filmed bearing machines
where a small shaft or reduced side-view is present:
l Radial vibration and radial position measurements
l Axial (thrust) position measurements
l Tachometer and zero speed measurements
l Phase reference (Keyphasor signals)
The 3300 XL NSv Transducer System design allows it to
replace both the 3300 RAM Transducer Systems and the
3000-series or 7000-series 190 Transducer System. Upgrades
from the 3300 RAM system to the 3300 XL NSv system may
use the existing probe, extension cable, and monitoring

Datasheet Link:

330980-50-05 Bently Nevada proximity measurement chains Datasheet
