Manufacture |
Bently Nevada |
|
Model |
101879-02 |
| PN No. |
101879-02 |
|
Catalog |
3300 system |
|
Description |
System Monitor Module |
| Origin | U.S.A. |
| HS CODE |
85389091 |
| Dimension |
38*32*4 (CM) |
| Weight | 0.6 kg |
Description:
The System Monitor performs four important tasks in a 3300 monitor rack,
providing:
Functions common to all monitors in the rack, such as:
- Alarm setpoint adjustment
- Keyphasor power, termination, conditioning, and distribution
- Alarm acknowledgement
Connection of all installed monitors to an external communications
processor (sold separately) via STATIC and DYNAMIC data ports.
Optional Serial Data Interface (SDI) for communication of transducer and
monitor data to process computers, digital/distributed control systems,
programmable controllers, and other control and automation systems.
Optional Dynamic Data Interface (DDI) for communication of transducer and
monitor data to compatible Bently Nevada machinery management software.
Depending on the type of data required, this option may eliminate the need for
an external communications processor
Datasheet Link:
3300/03-01-01 Bently Nevada Datasheet
