Manufacture |
ABB |
|
Model |
216MB66 |
| PN No. |
HESG324511M1 |
|
Catalog |
RE. 216 1MDU02005-EN |
|
Description |
Equipment rack |
| Origin | Germany |
| HS CODE |
85389099 |
| Dimension |
38*27*27 (CM) |
| Weight | 12.25 kg |
Description:
Equipment rack 216MB66 with parallel bus B448C
Figures 12.5 and 12.6 show the equipment rack without the plugin electronic units. The 19" rack is 21T (T = 17 mm) wide and 6U (U = 44.55 mm) high. The rack, the B448C parallel bus, the connectors for the standard cables and the terminal block form an invariable unit.
Settings
No settings have to be made to the equipment rack.
Care should be taken that the standard cables go to the appropriate connectors for the electronic units actually inserted. Refer also to Sections 2.2.1. and 2.2.2. and the set of specific plant diagrams.
sheet Link:
216MB66 HESG324511M1 Equipment rack PDF Datasheet
