Manufacture |
Vibration |
Model |
CPUM |
PN No. |
200-595-0Ss-33h |
Catalog |
NIL |
Description |
CPU card |
Origin |
Switzerland |
HS CODE |
85389091 |
Dimension |
26*20*5 (CM) |
Weight | 0.4 kg |
KEY FEATURES AND BENEFITS • From the Vibro-Meter® product line • VM600 CPUM/IOCN rack controller and communications interface card pair with support for Modbus RTU/TCP and PROFINET, and a front-panel display • “One-Shot” configuration management of protection cards (MPC4 and AMC8) in a VM600 rack using an Ethernet or RS-232 serial connection to a computer running the VM600 MPSx software • Front-panel display for visualisation of monitored outputs and alarm limits from protection cards • Front-panel alarm reset (AR) button • VM600 MPS rack (CPUM) security • Industry standard fieldbus communications interfaces: Modbus RTU/TCP and PROFINET • Two Ethernet connections and up to three serial connections (RS-232 / RS-422 / RS-485) can run simultaneously • Communications redundancy with multiple fieldbuses: Ethernet and/or serial KEY BENEFITS AND FEATURES (continued) • VM600 system event and measurement event logs available via the VM600 MPSx software • Supports live insertion and removal of protection cards (“hot-swapping”) with automatic configuration • Ethernet (100 Mbps) communication • Front-panel status indicators (LEDs) • Compatible with all VM600 ABE04x system racks APPLICATIONS • Rack controller for a VM600 system • Communications gateway between VM600 and third-party systems, such as a DCS or PLC • Enables sharing of measurement data from VM600 monitoring cards in machinery protection, condition monitoring and/or combustion monitoring applications
NEW AND ORIGIN ITEM IN STOCK
WITH ONE YEAR WARRANTY
Hope anyone enquire from us,pls click this sales6@nseauto.com
1. lower your support costs
2, Provide on-going availability of automation replacement parts
Quantity available: 1
Warranty: 12 months.
Lead time: 1-2 working days.
Terms of payment:T/T and Western Union.
Courier partners: DHL, UPS, TNT, FedEx and EMS.
Technical specification, manuals and data sheets
