Manufacture |
Vibration |
Model |
RPS6U |
PN No. |
200-582-500-02h |
Catalog |
NIL |
Description |
rack power supplies |
Origin |
Switzerland |
HS CODE |
85389091 |
Dimension |
30*28*12 (CM) |
Weight | 2.4 kg |
DESCRIPTION
Either one or two VM600Mk2/VM600 RPS6U rack
power supplies can be installed in a VM600Mk2/
VM600 ABE04x system rack. A rack with one
RPS6U power supply (330 W version) supports the
power requirements for a full rack of modules
(cards) in applications with operating
temperatures up to 50°C (122°F).
Alternatively, a rack can have two RPS6U power
supplies installed in order to either support rack
power supply redundancy or in order to supply
power to the modules (cards) non-redundantly
over a wider range of environmental conditions.
A VM600Mk2/VM600 ABE04x system rack with two
RPS6U power supplies installed can operate
redundantly (that is, with rack power supply
redundancy) for a full rack of modules (cards).
This means that if one RPS6U fails, the other will
provide 100% of the rack’s power requirement so
that the rack will continue to operate, thereby
increasing the availability of the machinery
monitoring system.
Note: This is known as a redundant RPS6U rack
power supply configuration.
A VM600Mk2/VM600 ABE04x system rack with two
RPS6U power supplies installed can also operate
non-redundantly (that is, without rack power
supply redundancy). Typically, this is only
necessary for a full rack of modules (cards) in
applications with operating temperatures above
50°C (122°F), where RPS6U output power derating
is required.
Note: Even though two RPS6U rack power supplies
are installed in the rack, this is not a redundant
RPS6U rack power supply configuration.
The number and type of RPS6U power supplies
installed in a VM600Mk2/VM600 ABE04x system
rack, together with the number of modules
(cards) installed and the environmental
conditions, helps determine the mode of
operation of the RPS6U power supplies as either
redundant or non-redundant. See also Ordering
information on page 16.
Different versions of the RPS6U rack power supply
enable a VM600Mk2/VM600 ABE04x system rack
to be powered using external AC and/or DC
mains supplies. All RPS6U power supplies support a
wide input voltage range.
A power supply check relay, available on the
associated rear panel at the rear of a VM600Mk2/
VM600 ABE04x system rack, is used to indicate
that the RPS6U power supplies are operating
normally. Refer to the VM600Mk2/VM600 ABE04x
system rack data sheet for further information.
In applications where the VM600Mk2/VM600
ABE04x system rack is powered by an AC mains
supply, a VM600Mk2/VM600 ASPS auxiliary sensor
power supply can also be included in the rack.
The ASPS provides +24 VDC outputs which can be
used by external sensor/measurement chain
hardware such as front-end sensors, signal
conditioners and galvanic separation units.
For further information, contact your local
Meggitt representative.
NEW AND ORIGIN ITEM IN STOCK
WITH ONE YEAR WARRANTY
Hope anyone enquire from us,pls click this sales6@nseauto.com
1. lower your support costs
2, Provide on-going availability of automation replacement parts
Quantity available: 1
Warranty: 12 months.
Lead time: 1-2 working days.
Terms of payment:T/T and Western Union.
Courier partners: DHL, UPS, TNT, FedEx and EMS.
Technical specification, manuals and data sheets
