Manufacture |
ABB |
|
Model |
TU851 |
| PN No. |
3BSE068782R1 |
|
Catalog |
S800 |
|
Description |
Terminal block |
| Origin | Sweden |
| HS CODE |
85389099 |
| Dimension |
12.6*11*6.4 (CM) |
| Weight | 0.22 kg |
Description:
The TU851 MTU can have up to 16 I/O channels. The maximum rated voltage is 250 V and maximum rated current is 3 A per channel. The MTU distributes the ModuleBus to the I/O module and to the next MTU. It also generates the correct address to the I/O module by shifting the outgoing position signals to the next MTU.
The MTU can be mounted on a standard DIN rail. It has a mechanical latch that locks the MTU to the DIN rail.
Two mechanical keys are used to configure the MTU for different types of I/O modules. This is only a mechanical configuration and it does not affect the functionality of the MTU or the I/O module. Each key has six positions, which gives a total number of 36 different configurations.
sheet Link:
TU851 ABB 3BSE068782R1 Terminal block PDF Datasheet
