100% Original ICS Triplex T8310 Module
Description
The Front Panel comprises a fault containment region (FCR D) separate from the other FCRs and contains non-critical functions. These include: • The diagnostics port and maintenance enable keyswitch mounted on the front panel of the Processor. • The serial communications drivers and the IRIG-B interface. These are accessed through the I/O connector via adapter units at the rear of the Processor. • Participates in all module voting operations. • Sends Fault/Fail signals to external indicators via the adapter units at the rear of the Processor. Two IRIG-B input standards are available to the Processor; IRIG-B002 and IRIG-B122. The standard used by the Processor is controlled by software setting a flag in the memory. The IRIG-B signals are used to synchronise systems and time-stamp entries in the Sequence of Events (SOE) log.Three serial communication options are available from the 4-channel Universal Asynchronous Receiver/Transmitter (UART). These are detailed as follows: • Channel 0 Front Panel Diagnostic Port (RS232) • Channel 1 Not configured • Channel 2 Communications Serial Port 2 (RS422/485) • Channel 3 Communications Serial Port 3 (RS422/485) The Trusted operating system (Trusted OS) is used in support of the Motorola Power PC series processor architecture. The real time kernel is a high speed, high functionality kernel made for fault tolerant distributed systems. The distributed communication is made transparent over all processors. The kernel provides basic services (such as basic memory management), and interference free software environments which allow software of various integrity levels to reside and co-operate in a single processing environment.
