Manufacture |
Vibration |
Model |
RPS6U |
PN No. |
200-582-600-013 |
Catalog |
NIL |
Description |
Power Supply |
Origin |
Switzerland |
HS CODE |
85389091 |
Dimension |
26*18*20 (CM) |
Weight | 2.4 kg |
NEW AND ORIGIN ITEM IN STOCK
WITH ONE YEAR WARRANTY
Hope anyone enquire from us,pls click this sales6@nseauto.com
1. lower your support costs
2, Provide on-going availability of automation replacement parts
Quantity available: 1
Warranty: 12 months.
Lead time: 1-2 working days.
Terms of payment:T/T and Western Union.
Courier partners: DHL, UPS, TNT, FedEx and EMS.
Technical specification, manuals and data sheets
SPECIFICATIONS:
Either one or two VM600Mk2/VM600 RPS6U rack
power supplies can be installed in a VM600Mk2/
VM600 ABE04x system rack. A rack with one
RPS6U power supply (330 W version) supports the
power requirements for a full rack of modules
(cards) in applications with operating
temperatures up to 50°C (122°F).
Alternatively, a rack can have two RPS6U power
supplies installed in order to either support rack
power supply redundancy or in order to supply
power to the modules (cards) non-redundantly
over a wider range of environmental conditions.
A VM600Mk2/VM600 ABE04x system rack with two
RPS6U power supplies installed can operate
redundantly (that is, with rack power supply
redundancy) for a full rack of modules (cards).
This means that if one RPS6U fails, the other will
provide 100% of the rack’s power requirement so
that the rack will continue to operate, thereby
increasing the availability of the machinery
monitoring system.
Note: This is known as a redundant RPS6U rack
power supply configuration.
A VM600Mk2/VM600 ABE04x system rack with two
RPS6U power supplies installed can also operate
non-redundantly (that is, without rack power
supply redundancy). Typically, this is only
necessary for a full rack of modules (cards) in
applications with operating temperatures above
50°C (122°F), where RPS6U output power derating
is required.
Note: Even though two RPS6U rack power supplies
are installed in the rack, this is not a redundant
RPS6U rack power supply configuration.
