MP3101 Invensys Triconex, TMR Main Processor

Description:

MP3101 is a main processor, manufactured by Invensys Triconex. A controller with a Model 3101 MP can include the following components:
• 1 Main Processor (MP) Baseplate assembly with 3 MP Modules
• 1 Communication Baseplate with up to 2 Communication Modules
• Up to 14 baseplates with up to 2 I/O modules per baseplate or up to 10
baseplates if using AO or PI Modules.
• Up to 15 Interconnect Assemblies
• I⁄O bus extender kits for each I⁄O column
• End Caps (top and bottom) for each column

Datasheet Link:

MP3101 Invensys Triconex, TMR Main Processor PDF Datasheet
