IS230TCATH1A BY GE MKVI, MKVIe, Core Analog Terminal Board

IS230TCATH1A GE MKVI, MKVIe, Core Analog Terminal Board

  • Item NO.:

    IS230TCATH1A
  • Payment:

    T/T
  • Price:

    $3000
  • Product Origin:

    U.S.A.
  • Shipping Port:

    Xiamen
  • Lead Time:

    5-7 days
  • Goods Stock:

    2
  • Product weight:

    2.5 kg

Manufacture
GE
Model
IS230TCATH1A
PN No.  IS230TCATH1A
Catalog
MKVI
Description
Core Analog Terminal Board
Origin U.S.A.
HS CODE 85389091
Dimension 35*25*8 (CM)
Weight 2.5 kg

Description:

IS230TCATH1A is a Core Analog (TCAT) terminal board assembly module developed by GE under the Mark VIe series. Additional I/O terminals for the PCAA module are provided by the Core Analog (TCAT) terminal board. It manages signals spread to one or three PCAA modules. There are twelve seismic inputs, twelve LVDT inputs, twenty-four 4-20 mA inputs, and two magnetic pulse rate inputs. All twenty-four 4-20 mA inputs have their own 24 V dc power source, with half on TCAT and the other half on an adjacent JGPA board.

IS230TCATH1A Features

TCAT outputs are made up of three voted signals ranging from 4 to 20 mA. 120 pluggable Euro-style box terminals provide field wire terminal points. A set of 48 terminals, a set of 24, and the second set of 48 terminals make up the terminal grouping.
12 extra 24 V dc outputs for 4-20 mA devices, as well as shield wire terminals, are provided by a JGPA board adjacent to the TCAT field terminals. TCAT connector P3 or P4 provides power to JGPA, which is a diode-or of power from the attached PCAA modules.
TCAT and one or more PCAA modules are connected via pairs of 68-pin connections. PR1 and PR2 are connected to the R IONet via a PCAA. PS1 and PS2 are connected to the S
IONet through a PCAA. PT1 and PT2 are connected to the T IONet via a PCAA.
Each cable connection has an electronic ID provided by TCAT. Cables are always used in pairs, and the electronic ID is used by PCAA to ensure that the correct TCAT cables are in place.
