IS200TDBSH6A GE MarkVI, Discrete I/O Board

Description:

GE developed the IS200TDBSH6A printed circuit board (PCB) as part of its Mark VI series. The Mark VI and other series in the Mark lineup were specifically designed for automating and managing industrial turbine systems.

The IS200TDBSH6A PCB is a substantial component. Centrally positioned on the upper half of this board are twelve black rectangular components arranged in three rows of four each. Flanking these black components on both sides are two long, rectangular grey components. Along the left edge of the IS200TDBSH6A, there are two green terminal blocks labeled TB1 and TB2. Each terminal block contains forty-eight terminals, numbered from one to forty-eight, and they are aligned vertically along the left edge. On the opposite side of the PCB, there is a mid-sized connector port with numerous small female connections. At least one solid yellow capacitor is located in the center of the IS200TDBSH6A directly below the twelve black components. Additionally, on the bottom left side of the IS200TDBSH6A, there are two resistors labeled R141 and R140. These resistors are yellow with a single thin black band at the center.

Datasheet Link:

IS200TDBSH6A GE MarkVI, Discrete I/O Board PDF Datasheet
