IS200SPROH1A GE MKVI, PPRO TERMINAL BOARD

Description:

The IS200SPROH1A is a square-shaped printed circuit card, also known as a printed circuit board (PCB). The entire left side of the IS200SPROH1A is taken up by a large, solid black terminal block. To the right of this terminal block, along the top edge of the IS200SPROH1A, there are two transformers placed side by side in a horizontal row. Most of these transformers are red with yellow and black parts on top. Directly below these transformers, there are two spaces that may contain small resistors. These resistors are yellow with a single black band in the middle. There are six rectangular black diodes arranged into two vertical rows of three diodes each, making a total of six. Three small yellow capacitors are placed beneath these diodes in a horizontal line. Several even smaller silver capacitors have been attached to the PCB towards the right center of the IS200SPROH1A. This Mark VI PCB also has two connector ports on its right half and a green terminal block on the left.

Datasheet Link:

IS200SPROH1A GE MKVI, PPRO TERMINAL BOARD PDF Datasheet
