IS200EXTBG2A GE EX2100, OBS: ORDER IS200EXHSG4A INSTEAD

Description:

The IS200EXTBG2A is the second variant of the Exciter Terminal Board (EXTB) series and is designated for simplex control, typically in contactor mode. It operates within the broader framework of the EX2100 series, working alongside several other boards. The primary function of the EXTB board is to facilitate de-excitation firing in conjunction with the EDEX board, which handles the initial de-excitation process.

This model, known as EXTB G2, features a configuration tailored for simplex control applications. It interfaces directly with the EMIO board via the EBKP backplane, ensuring seamless integration within the system architecture.

On the IS200EXTBG2A board, there are ten relays visibly mounted, though it has the capacity to host up to thirteen relays. These relays are categorized by their connections: C, M1, or M2, indicating their respective circuit linkages. Additionally, three varieties of capacitors—ceramic, electrolytic, and box types—are associated with this board model to support its operational requirements.

In terms of connectivity, the IS200EXTBG2A boasts a range of female plug connectors on its surface: three three-position plugs, one two-position plug, a six-position plug, and a twelve-position plug, facilitating diverse interfacing capabilities.

For comprehensive guidance on installing and operating the IS200EXTBG2A board, one should consult the GEH-6632 manual, where detailed information pertaining to the EXTB board can be found commencing on page forty-nine.
