Manufacture |
ABB |
|
Model |
INICT13A |
| PN No. |
INICT13A |
|
Catalog |
Infi 90 |
|
Description |
Computer Transfer Module |
| Origin | Sweden/Malta/India |
| HS CODE |
85389081 |
| Dimension |
20*20*6 (CM) |
| Weight | 0.5 kg |
Description:
The DEVICE definition block supports SCSI communication with the INICI03 and INICI13A. When a device block is configured, OPC90 will automatically detect the currently installed SCSI bus adapter(s) and search each adapter bus for INICI03 / INICI13A devices. Detected devices will appear in the primary and secondary port list boxes that are part of the DEVICE block properties. They are listed as devices like S0001:, S0002: etc. The ‘S’ indicates SCSI by the adapter card number, adapter bus number, adapter logical unit number and INICI03 SCSI target ID. Note that the target ID is the value set by switches on the Bailey INICI03 INICI13A module or INICI13A INICT13A module. The INICI03 or INICI13A must be powered up, configured to utilize its SCSI communication channel and attached to a PC SCSI host adapter card.Just about any PC SCSI card that supports external connection to the INICI03 IMMPIO1 module’s 50 pin SCSI socket or INICI13A SCSI 50 pin high density socket should work ok. Of course the SCSI card driver (provided by SCSI card manufacturer must also be installed).
Datasheet Link:
INICT13A ABB Infi-Net to Computer Transfer Module PDF Datasheet
