IC695CHS016 GE FANUC RX3i PWR330 Power Supply

Description:

Manufacture GE
Model   IC695CHS016
Ordering information  IC695CHS016
Catalog PWR330 Power Supply
Description  RH3i
HS Code 85389091
Dimension 16cm*16cm*12cm
Weight 1.0kg

About Us:

NEW AND ORIGIN ITEM IN STOCK

WITH ONE YEAR WARRANTY

Hope anyone enquire from us,pls click this sales6@nseauto.com
1. lower your support costs
2, Provide on-going availability of automation replacement parts
Quantity available: 1
Warranty: 12 months.
Lead time: 1-2 working days.
Terms of payment:T/T and Western Union.
Courier partners: DHL, UPS, TNT, FedEx and EMS.
Technical specification, manuals and data sheets

Details:

The GE Fanuc IC695CHS016 backplane is a universal backplane from the GE RX3i PACSystems series. It is a dual-bus universal backplane that is made to accommodate option modules, serial I/O modules, and PCI-based I/O modules. The IC695CHS016 universal backplane is made to be mounted horizontally on a rack in a GE RX3i PACSystems PLC. It needs about 4 inches or 102 millimeters of clearance around it on all sides so that it and the modules that it hosts can dissipate heat properly and experience air-cooling. The IC695CHS016 universal backplane comes with 16 slots and its dimensions are 5.6 inches x 23.7 inches x 5.8 inches in height, length, and depth, respectively.


The GE Fanuc RX3i PACSystems IC695CHS016 universal backplane with 16 slots needs an enclosure with an ingress protection rating of IP 20 or NEMA/UL Type 1 for safe operation in an industrial environment. Its internal current power ratings are 240 milliamps at 5 Volts DC and 600 milliamps at 3.3 Volts DC. The IC695CHS016 universal backplane is equipped with a grounding bar and a grounding point for protection. It supports serial expansion with its serial expansion connector. It can host modules that need 2 slots for installation as well as modules that need just 1 slot, and if there are any empty slots left once all the modules that the RX3i PACSystems PLC needs have been installed, they should be filled with filler modules. The filler modules will prevent the empty slots in the IC695CHS016 universal backplane from becoming dirty or corroded.
