The controller is equipped with 2 independent counters with inputs that can be configured for 5 V or 24 V voltage level. The required voltage level is determined by the user program with the Counter[0x].5/24V Mode system parameter.
Input A is the counter input, B is the count direction input and input Z (zero track) is used to reset. Alternatively, all inputs are 3-bit Gray code inputs (in decoder operation) The following modes of operation can be implemented:
Counter function 1 (depending on the count direction input signal)
Counter function 2 (not depending on the count direction input signal)
Decoder operation with attached absolute rotary transducer
The controller is equipped with 8 analog inputs with transmitter supplies for the unipolar measurement of voltages of 0...10 V, referenced to L-. With a shunt, also currents of 0...20 mA can be measured.
