DS200UPLAG1B GE OC2000 Main Processor Card, DS200UPLA no/fw

Description:

DS200UPLAG1BDA LAN Power Supply Board is a crucial member of its greater Mark V Series drive assembly. With this in mind, its is important to recognize this DS200UPLAG1BDA Power Supply Board's status as a revised Mark V Series product offering; as it is modified from its original DS200UPLAG1 parent circuit board status through its inclusion of three significant product revisions rated B, D, and A respectively. Two of the three revisions applied to this DS200UPLAG1BDA LAN Power Supply Board are considered functional product revisions, while the third revision is an A-rated artwork revision.

Hardware Tips and Specifications

Like any circuit board created by General Electric for their Mark V Series of turbine control systems, this DS200UPLAG1BDA LAN Power Supply Board makes use of an elevated number of hardware component inclusions and individual component specifications to achieve its intended functionality. The GE LAN Power Supply Circuit Board DS200UPLAG1BDA contains two 26-pin connectors, 1 fuse, and 1 toggle switch. The board also has 1 reset button and 1 8-pin connector. The GE LAN Power Supply Circuit Board DS200UPLAG1BDA also features two 26-pin connectors that send and receive control signals through a ribbon cable. The ribbon cable is made up of multiple fine wires that are connected to a plastic connector. The connector plugs into the pins in the connector on the board. This UPLA-abbreviated board is populated with 17 jumpers and 16 switches, for customization purposes. Some of the jumpers and switches are set at the factory and are only for use at the factory for testing purposes. Others can be used to configure the board for use by the site. When you replace the DS200UPLAG1BDA board, it is best practice to set the jumpers and switches on the replacement board exactly as they are set on the old board you are replacing.
