Description:

The GE DC Power Supply and Instrumentation Board DS200SDCIG1A serves as an interface to DC2000 drives. Troubleshooting and usability of the board is improved because each fuse has an LED indicator that indicates when the fuse with which it is associated blows. You must complete the following steps to view the board and check for a lit indicator LED light.

Open the cabinet in which the board is installed and inspect the board and note any LED lights that are lit. The potential exists for high-voltage being present on the board so do not touch the board or any components around the board. Write down any information about the identifier of the fuse. Then, remove all current from the drive. Open the cabinet and test the board to make sure all power is removed from the board. You might have to allow some time for all power to exit the board to avoid damage.
DS200SDCIG1A Features
To view the board and check for a bright indicator LED light, follow the instructions below.

Examine the board and any LED lights that are lighted by opening the cabinet in which it is installed. Because there is the possibility of high-voltage present on the board, do not touch it or any components nearby. Takedown all information you can regarding the fuse identify.
Remove all current from the drive after that. Open the cabinet and test the board to ensure that all power has been removed. To avoid damage, you may need to give the board some time to discharge all power.
DS200SDCIG1A Characteristics
Depending on which fuse has blown, you may be able to investigate the board for wiring faults or a short. It's possible that the board is defective and has to be replaced.
The component provides circuits to instrument a variety of AC line and DC motor signals, including armature current and voltage, field current and voltage, voltage magnitude, and phase sequence.
Keep the board from touching other boards or devices in the drive when removing it for inspection. Avoid touching the board's panels, cables, or the plastic snaps that keep it together. Also, make sure you remove any cables with care. Do not separate ribbon cables. Instead, separate the ribbon cable from the connector by holding both connectors with your fingers.
When ordering this board, all digits are crucial. Make sure that you order the correct SDCI board for your application.
