DS200FCGDH1B GE LCI Control and Gating Board

NEW AND ORIGIN ITEM IN STOCK

WITH ONE YEAR WARRANTY

Hope anyone enquire from us,pls click this sales6@nseauto.com
1. lower your support costs
2, Provide on-going availability of automation replacement parts
Quantity available: 1
Warranty: 12 months.
Lead time: 1-2 working days.
Terms of payment:T/T and Western Union.
Courier partners: DHL, UPS, TNT, FedEx and EMS.
Technical specification, manuals and data sheets

Description:

The DS200FCGDH1B is a gate distribution and status card (FCGD). Developed by General Electric for their Mark V board series, this card can be installed in a number of GE brand drives. When installed, this card acts as an interface system for the six pulse, phase controlled non-reversing bridge. The DSPC (digital signal processing card) relays information to this board to decipher. From this, signals regarding diagnostic information and system feedbacks are produced. These feedbacks are then sent out using the drive’s integrated VME backplane.

DS200FCGDH1B collects a large amount of data from the drive’s integrated DSPC. Signals received by the board are translated into cell gating signals. All system bridge legs receive this cell gating signals and return multiplexed cell status information to this card. Feedback signals are also received and scaled by the FCGD board. Three FGPA boards send feedback signals via fiber optic connections found on board. Included feedback are frequency, voltage, and board status information. An integrated IMOK LED status indicator provides users with basic system status.

Manufacturer provided installation parameters for the board should be met to minimize risk of device malfunction or error. Board function is dependent upon wiring the system correctly. An illustrated guide to wiring and installing DS200FCGDH1B is available in the device’s manual and datasheet. The entire Mark V series was originally provided technical support by General Electric.
