DS200DACAG1A GE AC/DC Power Converter Board

Description:

DS200DACAG1A is an AC/DC Power Converter Board manufactured by General Electric as part of the Mark V Series used in gas turbine control systems. The DACA module transforms ac input power from 115/230 V to 125 Vic output power. When a control system's main power source is 125V dc, with or without a battery, DACA is utilized. When the Mark VIe Control completely loses control power, DACA offers additional local energy storage in addition to power conversion to prolong the ride-through time.

Four specifically created brackets are used to bolt the DACA module to the cabinet's floor. One 12-position connector, designated JZ, is plugged into connectors JZ2 or JZ3 of the PDM and serves as both the dc output and the ac power input. The DACA internal cable is plugged into connector JTX1 for 115v or JTX2 for 230v to choose between those input voltages.
