Manufacture |
ABB |
|
Model |
DP820 |
| PN No. |
3BSE013228R1 |
| Catalog | 800xA |
| Description |
Pulse Counter RS-422 |
| Origin | Sweden/Malta/India |
| HS CODE |
8537109070 |
| Dimension |
20*14*16 (CM) |
| Weight | 0.4 kg |
Description:
DP820 3BSE013228R1 is an two-channel pulse counting module for incremental pulse transmitters up to 1.5 MHz. Each channel contains counters and registers for position/length and speed/frequency measurement. Each channel provides three balanced inputs for connection of a pulse transmitter, one digital input and one digital output. Pulse transmitters with RS422, +5 V, +12 V, +24 V and 13 mA interfaces can be connected to DP820.
Use DP820 with Module Termination Units TU810V1, TU812V1, TU814V1, TU830V1, TU833.
Features and benefits:
-Two channels
-Interface for RS422, 5 V, 12 V, 24 V and 13 mA transducer signal levels
-Simultaneous pulse count and frequency measurement
-Pulse count (length/position) by accumulation in a bidirectional 29 bit counter
-Frequency (speed) measurement 0.25 Hz - 1.5 MHz
Frequently Asked Questions:
1.What is the payment term?
Wire transfer only.
2.When does the warranty period start?
One year from the time the client receives the goods.
Datasheet Link:
DP820 ABB 3BSE013228R1, Pulse Counter RS-422 PDF Datasheet
