Manufacture |
ABB |
|
Model |
88VT02E |
| PN No. |
88VT02E |
|
Catalog |
BBC |
|
Description |
Telegram Handling Module |
| Origin | Sweden |
| HS CODE | 85389099 |
| Dimension |
1.98*0.2*2.61 (CM) |
| Weight | 0.5 kg |
Description:
The telegram handling module is part of the entire master station bus control(consisting of modules 88VA01/VA02,88VP01/VPO2,88VTO1/VTO2). As an"auxiliary module" of the processor, it handles the serial telegrams.
However, each subfunction is only performed when called by aspecific command from the processor module 88VP01/VP02. The commands come from the command fields of the 48-bit data word of the program memory (see module description "Master station processor module 88VP01/VP02"，GKWE 705180). The commands are transferred in coded form via the general-bus and are decoded on the module (the decoders are not shown in the functional diagram).
In the following, the most important functional sections are specified and their functions with in the entire program of the master station bus control are described (see also"Funct ionadiagram" ).
However, each subfunction is only performed when called by aspecific command from the processor module 88VP01/VP02. The commands come from the command fields of the 48-bit data word of the program memory (see module description "Master station processor module 88VP01/VP02"，GKWE 705180). The commands are transferred in coded form via the general-bus and are decoded on the module (the decoders are not shown in the functional diagram).
In the following, the most important functional sections are specified and their functions with in the entire program of the master station bus control are described (see also"Funct ionadiagram" ).
sheet Link:
88VT02E ABB Telegram Handling Module PDF Datasheet
