Manufacture |
ABB |
|
Model |
88QT03E |
| PN No. |
88QT03E |
|
Catalog |
Procontrol P
|
|
Description |
Bus Coupling Module |
| Origin | Sweden |
| HS CODE | 85389099 |
| Dimension |
1.98*0.2*2.61 (CM) |
| Weight | 0.5 kg |
Description:
The 88QT03 bus coupling module is used to connect PROCONTROL P to the bus of the PROCONTROL ---PS protection
system. The following PROCONTROL ---PS modules can be
connected:
--- 70EA01 ---ES/R1 Analog input module
(one data telegram per function unit)
--- 70EA02 ---ES/R1 Analog input module
(one data telegram per function unit)
--- 70EB02 ---ES/R4 Binary input module
(one data telegram per module)
--- 70AB01 ---ES/R2 Binary output module
(one data telegram per module)
--- 70PR03 ---ES/R2 Computing module
--- 70BK03 ---ES/R2 Bus coupling module
(RS485 interface)
--- 70BT01/R1 Bus isolation amplifier
--- 70BV01 ---ES/R1 Bus control module
Connected to the station bus, the module behaves like a combined input/output module that is able to receive up to 255
telegrams from the station bus and send up to a maximum of
200 telegrams to the station bus.
a processing module receiving and sending a total of up to
256 telegrams.
sheet Link:
88QT03E ABB Bus Coupling Module PDF Datasheet
