Manufacture |
ABB |
|
Model |
88FN02E |
| PN No. |
88FN02E |
|
Catalog |
BBC |
|
Description |
Bus Coupling Module |
| Origin | Sweden |
| HS CODE | 85389099 |
| Dimension |
1.98*0.2*2.61 (CM) |
| Weight | 0.5 kg |
Description:
88 FN01-E/R0100 or 88 FN02-E/R0100 respectively : 160 mm deep for use in the muti-purpose processing stations
88 FN01-E/R0200 or 88 FN02-E/RO200 respectively : 220 mm deep for use in the master stations.
Both versions(R0100 or R200 respectively) are identical in respect of their module functions. Version 88FN2 supersedes 88 FN01.
The module is provided with a standard interface to the remote bus and a standard interface to the PR0C0NTROL local bus.
A selecting ciruit pemmits the connection of two remote bus lines to the coupling module(if the bus system is of redundant design).
Any disturbances detected by the monitoring circuits are signalled by a light-emitting diode(ST)at the front of the remote bus modules.
Continuous transmitter disturbances are indicated on the front side of the module by light-emittingdiode QA and QB respectively.
A connecting socket is prvided at the front ofthe module to whichthe local bus is connected. The service and commissioning device can be connected to this socket.
88 FN01-E/R0200 or 88 FN02-E/RO200 respectively : 220 mm deep for use in the master stations.
Both versions(R0100 or R200 respectively) are identical in respect of their module functions. Version 88FN2 supersedes 88 FN01.
The module is provided with a standard interface to the remote bus and a standard interface to the PR0C0NTROL local bus.
A selecting ciruit pemmits the connection of two remote bus lines to the coupling module(if the bus system is of redundant design).
Any disturbances detected by the monitoring circuits are signalled by a light-emitting diode(ST)at the front of the remote bus modules.
Continuous transmitter disturbances are indicated on the front side of the module by light-emittingdiode QA and QB respectively.
A connecting socket is prvided at the front ofthe module to whichthe local bus is connected. The service and commissioning device can be connected to this socket.
sheet Link:
88FN02E ABB Bus Coupling Module PDF Datasheet
