Manufacture |
ABB |
|
Model |
81EA02E |
| PN No. |
GJR2366000R1000 |
|
Catalog |
PROCONTROL 13 |
|
Description |
Analog Input Module |
| Origin | Sweden |
| HS CODE |
85389099 |
| Dimension |
1.98*0.2*2.61 (CM) |
| Weight | 0.42 kg |
Description:
The module 81EA02E GJR2366000R1000 can be plugged into any multi -purpose processing station of the PROCONTROL bus system. It incorporates a standard interface to the PROCONTROL station ---bus.
The telegrams received via the station ---bus are checked by the module for faultless transfer by means of parity bits.
The telegrams sent from the module to the station ---bus are provided with parity bits. This ensures faultless transfer.
A voltage source that is supplied with US = +24 V is available for each function unit when connecting two ---wire transducers in the range 4...20 mA.
The input signals are supplied to the processing section via an isolation facility. This eliminates any interaction between the process side and the bus side.
The following annunciations are signalled at the front of the module by light ---emitting diodes:
--- Module disturbance --- ST
--- Simulation --- SIM
Switches and plug ---in jumpers are provided on the module for setting the operating modes.
Interference voltages on the input lines are suppressed by module ---internal protective circuits.
sheet Link:
81EA02E ABB GJR2366000R1000 Analog Input Module PDF Datashee
