3500/22M 138607-01 BENTLY NEVADA TDI Module

Brand new with low price,welcome quote for it

  • Item NO.:

    3500/22M
  • Payment:

    T/T
  • Product Origin:

    U.S.A.
  • Color:

    Depends on material
  • Shipping Port:

    Xiamen
  • Lead Time:

    5-7 days
  • Goods Stock:

    99
  • Product weight:

    0.8 kg


Manufacture
BENTLY NEVADA
Model
3500/22M
PN No. 138607-01/288055-01
Catalog
3500
Description
Transient Data Interface
Origin U.S.A.
HS CODE 85389091
Dimension 30*23*8 (CM)
Weight 0.8 kg

Description
The 3500/22M Transient Data Interface (TDI) is the interface between the 3500 monitoring system and compatible software (System 1 Condition Monitoring and Diagnostic software and 3500 System Configuration software). The TDI combines the function of a 3500/20 Rack Interface Module (RIM) with the data collection capability of a communication processor such as TDXnet.
The TDI resides in the slot adjacent to the power supplies of a 3500 rack. It interfaces with M series monitors (3500/40M, 3500/42M, etc.) to continuously collect steady state and transient dynamic (waveform) data and pass this data through an Ethernet link to the host software. Refer to the Compatibility section at the end of this document for more information.
Static data capture capability is standard with the TDI. However, using an optional Channel Enabling Disk will allow the TDI to capture dynamic and high-resolution transient data as well. The TDI incorporates the communication processor function within the 3500 rack.
Although the TDI provides certain functions common to the entire rack, it is not part of the critical monitoring path and has no effect on the proper, normal operation of the overall monitor system for automatic machinery protection. Every 3500 rack requires one TDI or RIM, which always occupies Slot 1 (next to the power supplies).


NEW AND ORIGIN ITEM IN STOCK

WITH ONE YEAR WARRANTY

Hope anyone enquire from us,pls click this sales6@nseauto.com
1. lower your support costs
2, Provide on-going availability of automation replacement parts
Quantity available: 1
Warranty: 12 months.
Lead time: 1-2 working days.
Terms of payment:T/T and Western Union.
Courier partners: DHL, UPS, TNT, FedEx and EMS.
Technical specification, manuals and data sheets

3500/22M TDI Module and I/O
3500/22-AA-BB-CC
A: Transient Data Interface Type
01 Standard (use for standard monitoring
applications)
B: I/O Module Type
01 10Base-T/100Base-TX Ethernet
02 100Base-FX (Fiber Optic) Ethernet
03 10Base-T/100Base-TX Ethernet with goldplated
OK Relay contacts
04 100Base-FX (fiber optic) Ethernet with goldplated
OK Relay contacts
C: Agency Approval
00 None
01 CSA/NRTL/C (Class 1, Division 2)
02 Multi (CSA, ATEX, IECEx)

Spares
288055-01 Standard Transient Data Interface
Module with USB cable
123M4610* 10 foot A to B USB cable
146031-01 10Base-T/100Base-TX I/O Module
146031-02 100Base-FX (Fiber Optic) I/O Module
161580 3500/22M TDI Operation and
Maintenance User Guide
164466 Network Accessories Datasheet
00580441 Connector header, internal
termination, 3-position, green
00580436 Connector header, internal
termination, 6-position, green
111M5777 Connector header, internal
termination, 2-position, green
