330130-080-01-00 Bently Nevada, 3300XL Standard Extension Cable

Description:

3300 XL 330130-080-01-00, Metric:
 Cable Length Option: 8.0 meters (26.2 feet)

 Connector Protector and Cable Option: Armored cable
 Agency Approval Option: Not required

The 3300 XL probe and extension cable also reflect improvements over previous designs. A patented TipLoc molding method provides a more robust bond between the probe tip and the probe body. The probe’s cable incorporates a patented CableLoc design that provides 330 N (75 lbf) pull strength to more securely attach the probe cable and probe tip.
You can also order 3300 XL 8 mm probes and extension cables with an optional FluidLoc cable option. This option prevents oil and other liquids from leaking out of the machine through the cable’s interior.

Frequently Asked Questions:
1.What is the 330130-080-01-00 Extended Temperature Range?

An extended temperature range (ETR) probe and ETR extension cable are available for applications in which either the probe lead or extension cable may exceed the standard 177˚C (350˚F) temperature specification. The ETR probe has an extended temperature rating for up to 218˚C (425˚F). The ETR extension cable rating is up to 260˚C (500˚F). Both the ETR probe and cable are compatible with standard temperature probes and cables, for example, you can utilize an ETR probe with the 330130 extension cable. The ETR system uses the standard 3300 XL Proximitor Sensor. Note that when you use any ETR component as part of your system, the ETR component limits the system accuracy to the accuracy of the ETR system.

2.What is the payment term?
Only wire transfer

3.When does the warranty period start?

One year from the time the client receives the goods.

Datasheet Link:

330130-080-01-00 Bently Nevada, 3300XL Standard Extension Cable PDF Datasheet
