3300/12 Bently Nevada, AC Power Supply

Description:

The 3300/12 AC Power Supply is a reliable and robust power solution designed to deliver regulated power for up to 12 monitors and their associated transducers. Manufactured by Bently Nevada, this power supply is installed in the left-most position of a 3300 rack and is capable of converting 115 Vac or 220 Vac into DC voltages required by the monitors in the rack. Equipped with a line noise filter as standard, it ensures clean and stable power supply. The unit is designed to operate within a wide range of temperatures and is compliant with various safety standards, including CE Mark Directives and hazardous area approvals such as CSA/NRTL/C and ATEX.

Key Features:
- Converts 115 Vac or 220 Vac to DC voltages.
- User-programmable transducer power outputs: -24 Vdc or -18 Vdc.
- Overload protection per channel on individual monitor circuit boards.
- Hermetically-sealed OK Relay for reliable operation.
- Environmentally sealed to withstand temperatures from 0°C to +65°C.
- Compliance with CE Mark Directives and Low Voltage Directive.
- Hazardous area approvals for safe operation in Class I, Div 2 environments.

Frequently Asked Questions:

1. What is the input voltage range for the 3300/12 AC Power Supply?
The input voltage range is 95 to 125 Vac, single phase, 50 to 60 Hz, at 1.0 A maximum, or 190 to 250 Vac single phase, 50 to 60 Hz, at 0.5 A maximum.

2. What type of relay does the 3300/12 AC Power Supply use?
It uses a single-pole, double-throw (SPDT) relay that is hermetically-sealed.

3. What are the environmental operating temperature limits for the 3300/12 AC Power Supply?
The operating temperature limits are from 0°C to +65°C (+32°F to +150°F).

Datasheet Link:

3300/12 Bently Nevada, AC Power Supply PDF Datasheet
