Manufacture |
ABB |
|
Model |
07KT98 |
| PN No. |
GJR5253100R0272 |
|
Catalog |
Advant Controller 31 |
|
Description |
Basic Unit |
| Origin | Sweden/Malta/India |
| HS CODE |
85389081 |
| Dimension |
20*8*6 (CM) |
| Weight | 0.5 kg |
Description:
The Ethernet coupler is an intelligent 100-Base-T-Ethernetcommunication interface based on the highly integrated
microcontroller EC1. The coupler supports the complete
TCP/IP protocol and the application layers, too.
The user interface is based on a dual-port memory.
The coupler meets the PC/104 standard. It is powered by
the internal 5 V supply voltage.
The Ethernet communication is run via an RJ45 interface.
In addition, the coupler has a diagnosis interface in Mini-
DIN format.
The coupler is configured via the dual-port memory, the
diagnosis interface or a TCP/IP connection by means of
a system configurator. The configuration is saved nonvolatile
in a Flash EPROM.
Basic units with integrated Ethernet coupler
07 KT 98 R270 (Ethernet) Order No. GJR5 2531 00 R0270
07 KT 98 R272 (Ethernet + PROFIBUS-DP) Order No. GJR5 2531 00 R0272
07 KT 98 R276 (Ethernet + ARCNET) Order No. GJR5 2531 00 R0276
07 KT 98 R277 (Ethernet + Ethernet) Order No. GJR5 2531 00 R0277
07 KT 98 R278 (Ethernet + CANopen) Order No. GJR5 2531 00 R0278
Datasheet Link:
07KT98 ABB GJR5253100R0272 Basic Unit PDF Datasheet
